Home/Products/Bronze Powder/
Pre-Alloyed Bronze 90/10
Pre-Alloyed Bronze Powder 90/10
BR-9010
Br
Product SKU

Pre-Alloyed Bronze Powder 90/10

90Cu/10Sn pre-alloyed bronze powder for diamond tool bond matrices and sintered components. Consistent phase distribution, controlled sintering behaviour.

Request a QuoteFull Specifications ↓
Product Identity
SKU Code
BR-9010
Material
Bronze
Production
Pre-Alloyed Atomised
Morphology
Irregular / Spherical
Grades
-100, -200, -325
Purity
Cu 90% / Sn 10% (nominal)
Apparent Density
2.5 – 3.5 g/cc
Flow Rate
Non-flowing to 28 sec/50g
Availability
UK Stock
Request Technical Data SheetRequest Safety Data Sheet
48hr
UK
Dispatch
ISO
9001 & 14001
Certified
Silver
EcoVadis
Medal
20+
Countries
Supplied
Pre-Alloyed Bronze Powder 90/10

Available Grades

Standard grades held in UK stock; other grades and particle sizes made to order.

DescriptionComposition (%)App. Density (g/cc)Size (µm)
Pre-Alloyed Bronze 90/10 -100#Cu 90 / Sn 102.5–3.5< 150
Pre-Alloyed Bronze 90/10 -200#Cu 90 / Sn 102.5–3.5< 75
Pre-Alloyed Bronze 90/10 -325#Cu 90 / Sn 102.5–3.5< 45

* Made to order  ·  Stock item unless noted  ·  Pricing is commodity-linked — contact us for a current quotation.

Full Specifications

BR-9010

Technical Data

BR-9010 is Ronald Britton's 90Cu/10Sn pre-alloyed bronze powder for diamond tool bond matrices, powder metallurgy and sintered structural components. Pre-alloyed composition ensures consistent phase distribution and eliminates segregation. Available in -100, -200 and -325 mesh grades from UK stock.

BR-9010
 Range — Typical Properties
PropertyValue
SKU CodeBR-9010
MaterialBronze (Cu-Sn 90/10)
Production MethodPre-alloyed atomisation
Particle MorphologyIrregular / Spherical
Available Grades-100, -200, -325 mesh
CompositionCu 90% / Sn 10% (nominal)
Apparent Density2.5–3.5 g/cc
Flow Rate (Hall)Non-flowing to 28 sec/50g
Hydrogen Loss0.40% max
Green StrengthGood
ColourGolden bronze
CoA
Certificate of Analysis
Every Shipment
Batch
Full
Traceability
PSD
Particle Size Distribution
Verified
Related Products

You Might Also Need

BR-8515
Pre-Alloyed Bronze Powder 85/15
BR-8515 is Ronald Britton's 85Cu/15Sn pre-alloyed bronze powder, offering higher tin content for harder, more wear-resistant bond matrices in diamond tools. Used in aggressive cutting applications including reinforced concrete, granite and hard stone sawing.
Purity
Cu 85% / Sn 15% (nominal)
Morphology
Irregular
App. Density
2.0 – 3.0 g/cc
View product →
SN-100
Spherical Tin Powder
SN-100 is Ronald Britton's spherical tin powder, 99.5% minimum purity, available in -100, -200 and -325 mesh grades. Used as alloying addition in bronze and brass blending, brazing filler metal formulation, and as a low-melting additive in diamond tool bond matrices.
Purity
Sn 99.5% min
Morphology
Spherical
App. Density
3.5 – 4.5 g/cc
View product →
CU-ED
Electrolytic Dendritic Copper Powder
CU-ED is Ronald Britton's electrolytic dendritic copper powder, available in five grades (STD, SFP2, SFP3, SFP8, SFP10) with apparent densities from 0.65 to 2.7 g/cc and copper purity of Cu 99.0% minimum. Dendritic particle morphology provides excellent compressibility and green strength for pressed diamond tool segments, powder metallurgy components, and sintered metal parts. Non-flowing. UK stock, 48-hour dispatch. ISO 9001 and ISO 14001 certified.
Purity
Cu 99.0% min
Morphology
Dendritic
App. Density
0.65 – 2.7 g/cc
View product →
Reference Tool

Mesh ↔ Micron Converter

Instantly convert between standard mesh sizes and micron measurements.

⇄︎
Mesh ⇄︎ Micron Converter
Interactive
Mesh Size
-100
⟷
Microns (µm)
150
QUICK SELECT
-40-60-80-100-120-150-170-200-230-270-325-400

Quick tip: the minus sign in mesh sizes (e.g. -200) means the powder passes through that sieve, so -200 mesh means every particle is smaller than 75 µm.

Read the full guide →

CU-ED range: STD (-100#), SFP2/SFP3 (-300#), SFP8 (-240#), SFP10 (-300#)

Recommended Applications

Where

BR-9010

Performs Best

Typical applications for this grade. Our technical team can advise on the best grade for your process.

  • Diamond tool bond matrices (saw blades, drill bits, grinding wheels)
  • Powder metallurgy components
  • Sintered structural parts
  • Cold casting and decorative composites
Frequently Asked Questions

BR-9010

Questions & Answers

What is BR-9010 pre-alloyed bronze powder used for?

BR-9010 is the workhorse bond matrix powder for diamond tool segments (saw blades, drill bits, grinding wheels) and is also used in powder metallurgy components, sintered structural parts and cold casting. The 90/10 Cu:Sn ratio balances hardness, toughness and sinterability.

Why choose pre-alloyed bronze over blended copper and tin?

Pre-alloyed powder carries the 90/10 composition inside every particle, so there is no segregation during handling and the alloy sinters with consistent phase distribution. Blended elemental powders offer ratio flexibility but demand tighter process control.

What mesh sizes and properties does BR-9010 offer?

BR-9010 comes in -100, -200 and -325 mesh with apparent density of 2.5 to 3.5 g/cc and hydrogen loss of 0.40% max. Finer grades give more uniform sintering and are typical for premium diamond tool segments.

When should I use BR-8515 instead?

Move to BR-8515 (85/15) when the application needs a harder, more wear-resistant matrix, for example cutting granite, reinforced concrete or other aggressive materials. Higher tin content raises matrix hardness at some cost in toughness.

Can I order small or sample quantities of BR-9010?

Sample quantities are available for formulation trials. UK stock grades typically dispatch within 48 hours in 1 kg, 5 kg or 25 kg packaging.

What documentation is supplied with BR-9010?

Every batch ships with ISO 9001 certified documentation, chemical analysis and batch traceability. Technical and Safety Data Sheets are available on request, with export handled for international customers.
Cu-Sn
Material Hub
Bronze Powder
90/10 and custom copper-tin ratio blends. Our highest-volume product line. The critical binder matrix in diamond tool manufacture and cold casting applications.
View all grades →
